LiFePO4 12V 200AH VP Lithium Rechargeable Battery Customized Energy Storage System
Performance Characteristics:
· High energy density enables compact design with superior power output
· Short time rapid charging and low maintenance cost
· -20~+60°C widely temperature range
· Certified to MSDS / UN38.3 / CE standards
· LiFePO4 cells, High Consistency, Long cycle life and much more safety
Specifications:
| Model |
VP12200PLUS |
| Standard Voltage |
12.8V |
| Rated Capacity |
200Ah / 2560Wh |
| Dimensions (LWH) |
556*240*298 mm |
| Recommended Charge / Discharge Current |
0.5C |
| Max Continuous Operating Current |
200A |
| Max Peak Current (3-5s) |
400A |
| Net Weight |
20.8kg |
| Cycle Life |
≥4000 cycles @70% DOD (optional) |
| Communication |
Bluetooth |
| Waterproof Grade |
ABS / IP65 |
| BMS (optional) |
Hardware / Software |
Meet the VP12200PLUS, a robust 12V 200Ah LiFePO4 energy storage system built for resilience. Its IP65-rated enclosure makes it fearless of wind and rain, while its design ensures stable operation in both cold and high temperatures. It delivers a stable voltage output, capable of powering various household appliances and different loads within its range. This system comes equipped with multiple built-in protection functions (including over-charge, over-discharge, over-current, and short-circuit protection) to comprehensively safeguard your power supply and equipment.
Our Factory:
Experience true end-to-end value with Guangzhou Victory Tech’ integrated manufacturing model. From in-house production of key components to final assembly and testing, we maintain full control over quality and cost—passing the savings and reliability on to you. As an established battery factory in China, we supply lithium batteries, dry cell batteries, and scalable energy storage systems, all customizable through OEM / ODM. Our significant production capacity ensures timely delivery for large projects, while dedicated business support and local after-service engineers safeguard your investment. Choose VP Batteries for seamless integration, from design to delivery and beyond.
Applications:
This reliable home energy storage system serves multiple critical roles. It integrates seamlessly with Solar-Wind Power Systems and functions as a Back-up Power Source/UPS during grid outages. It powers Power Tools, Security Systems, Electronics, POS systems, and various LED & Emergency Lighting for homes and businesses. Furthermore, it is suitable for supporting Telecom Bases, CATV systems, and other infrastructure. Its design also makes it compatible for use in Commercial & Transit applications including RVs, Marine use, E-bikes, Golf Carts, and Electric Wheelchairs.
Notices:
1. Use flame-retardant cables for battery connection, with clear positive and negative pole markings to prevent short-circuit hazards.
2. Maintain 20-80% SoC for cycle life preservation.
3. We recommend that batteries be charged about once per half a year to or event over discharge.
4. Prohibited to install in flammable environments, humidity > 95% or dusty areas.
5. Confirm the device voltage based on parameters such as the number of battery packs. Maintain a consistent voltage, otherwise the device may burn out.
FAQ
Q: Do you sell your batteries globally?
A: Yes, we do. VP batteries are sold worldwide and have earned certifications from the International Electrotechnical Commission ( IEC ), CE, ROHS, SGS, and ISO9001.
Q:What are your company's strengths?
A:We only provide high quality batteries, guarantee on-time shipment, and also provide excellent after-sales service.
Q: Can you handle large volume orders?
A: Absolutely. At Guangzhou Victory Technology Co., Ltd., we've got a staggering production capacity of billion batteries annually. No matter how large the volume of your order, we're prepared to deliver.
Q: How long does it take to ship after an order is completed?
A: The shipping time depends on the scale of the order and specific requirements. We provide an estimated shipping time after the order is confirmed.
Q:How to maintain the battery?
A:The battery should be stored in clean, dry, ventilated, dark environment when not using, keep it after full charge, recharge it every 3 months or 6 months.
Ready to Specify or Private Label? Contact our B2B sales team for:
- Volume-based commercial quotations.
- Detailed OEM / ODM service guide.
- Full technical documentation and certification packages.
